When using a high modulus silicone sealant like Geocel HM, correct curing conditions and joint design are crucial for long-term performance.
Whether you’re sealing sanitary joints, internal perimeters, or commercial installations, understanding how the sealant cures — and how to design the joint properly — makes the difference between a lasting seal and premature failure.
In this guide, we’ll break down:
How Geocel HM cures,
What affects its curing speed,
And how to design joints to get the best possible performance from your high modulus silicone.
What Is Geocel HM?
Geocel HM is a high modulus acetoxy-cure silicone sealant designed for internal sealing applications such as bathrooms, kitchens, and sanitary joints. It provides a tough, durable seal with excellent adhesion to glass, enamel, and ceramic surfaces.
As a high modulus product, it forms a firmer, less elastic joint than low modulus silicones — ideal for static joints or where strong adhesion and resistance to movement are required.
How Geocel HM Cures
Geocel HM cures through a moisture reaction — once applied, it reacts with atmospheric moisture to form a flexible, rubber-like material.
Typical Curing Time:
Skin formation: ~10–20 minutes at 23°C and 50% relative humidity.
Full cure: 1–2 mm per 24 hours (depending on humidity and joint depth).
Because it’s an acetoxy silicone, curing time can vary based on temperature and air circulation. In colder or low-humidity environments, curing slows down; in warm, humid conditions, it accelerates.
Pro Tip:Always allow sufficient curing time before exposing the joint to water or cleaning products — ideally 24 hours minimum for sanitary applications.
Humidity: Acetoxy silicones rely on moisture to cure — dry air will delay full cure.
Joint Depth: Deep or wide joints cure slower due to limited exposure to air.
Substrate Type: Non-porous materials (like glass or metal) slow down moisture penetration compared to porous surfaces.
To ensure full cure, apply Geocel HM in moderate conditions (between 5°C and 40°C) and avoid sealing in extremely dry or cold weather.
High Modulus Joint Design Explained
Joint design plays a huge role in sealant performance — particularly with high modulus products like Geocel HM, which don’t stretch as much as low modulus alternatives.
Key Design Considerations:
Joint Depth-to-Width Ratio: Aim for a2:1 width-to-depth ratio (e.g., 10 mm wide x 5 mm deep).
Backer Rod:Always use a polyethylene backer rod in deeper joints to control sealant depth and prevent three-sided adhesion.
Movement Expectation: High modulus sealants are best for static joints — low or no movement.
Substrate Preparation:Clean thoroughly with a suitable solvent and ensure surfaces are dry before application.
These principles help the sealant absorb movement efficiently and maintain strong adhesion across the joint without tearing or loss of bond.
Common Application Mistakes to Avoid
Overfilling the joint: Too much material increases cure time and may cause bubbling.
Incorrect surface prep: Residues like dust or oil will reduce adhesion.
Poor tooling: Uneven finishes can trap air, affecting cure uniformity.
Sealing in cold or dry air: Significantly slows curing and weakens bond strength.
Following correct application methods ensures Geocel HM cures evenly and forms a long-lasting, professional-quality seal.
When to Use Geocel HM in Your Project
Geocel HM is perfect for:
Bathroom and kitchen joints
Ceramic or glass sealing
Areas where firm, non-flexing joints are preferred
For dynamic or expansion joints, a low modulus sealant (such as Dowsil C60) may be more appropriate — offering better flexibility and movement accommodation.
Final Tips for a Long-Lasting Seal
Always check product datasheets for specific curing times and substrate compatibility.
Maintain room temperature between 15°C and 25°C during application.
Allow 24–48 hours before exposure to water or cleaning.
